1. Stone Mitre Clamps are mainly used for 45 degrees stitching among quartz stone, natural stone, or other similar plate materials.
2.45-degree clamps are designed for perfect positioning and locking fascia (apron) to your countertop via miter joint. Its adjustable jaw allows holding various height and thicknesses. By combining two or more 90° Clamp, longer lengths can be accommodated.
3. Placed on the 45 ° stitching of two workpieces, put two workpieces of 45 ° bevel face assembling together, and the two 45°workpiece fit into a 90 with each other.
4.Available sizes: Large (max. 300mm opening)
Small (max. 130mm opening)
HIGH-TECH 90 Degree /45 Degree Stone Mitre Clamp
Small 45-degree miter clamp with max.130mm opening
Made with lighter metal and hard plastic knobs.
Size:200x50x320mm
Technical Specification：
| Max. processing height |
Max. Joint Angle |
Overall Size and Weight |
| 130mm |
90° |
2.3KG |
| 300mm |
90° |
4.2KG
|
Advantages:
-
Reduce preparation time by 75%
-
Save more labor costs
-
Create high-quality 90-degree seams
-
Provide tight seams
-
Ensure accurate alignment
-
Protect tools from exceeding the glue
-
Long-term investment
-
Fast service respond
Tips for use：
1. 45 ° diagonal clamp is mainly used for (artificial and natural stone) or other similar sheets of 45 stitches.
2. When the two elements are processed into a 45-edge phase, clean the 45-part workpiece, evenly covered with adhesive, and then place the two workpieces with the 45-phase mounting surface together, and the two 45-degree elements fit into the '90s with each other, use fittings in plastic seams for extrusion.
3. First, put a stone with a bottom width on the work surface of the fixture with white rubber, the side of a narrow stone near the inside of the device.
4. Then, the two adhesive levers can be adjusted by setting the spring device access to the upper position of the workpiece and then rotating the screw at the top of the adhesive lever to apply pressure to keep the device locked for some time until the workpiece is completely solidified, reliably, then release the device.
5. Use one 45 degrees fixture at every 30CM distance while working.
Delivery Date:
5-15 days after confiming payment, the delivery date should be negotiated according to production season and order quantity.
Exhibition:
Delivery Plans:
• Air Freight: 3-5days
• Courier (TNT/DHL/UPS/EMS/SF EXPRESS/FEDEX):5-8days
• Sea: 15-30days
